Technische specificaties
Processor
| Processorfabrikant | Intel |
| Processor socket | LGA 1700 |
| Compatibele processors | Intel Celeron,Intel Pentium Gold |
| Supported processor sockets | LGA 1700 |
Geheugen
| Ondersteunde geheugen types | DDR5-SDRAM |
| Aantal geheugenslots | 4 |
| ECC-compatibiliteit | non-ECC |
| Supported memory clock speeds | 4800,5000,5200,5400,5600,5800,6000,6200,6400,6600,6800 |
| Maximum intern geheugen | 256 |
| Niet gebufferd geheugen | Y |
Opslag-controllers
| Ondersteunde types opslag-drives | HDD & SSD |
| Ondersteunde opslagstationinterfaces | SATA III |
| Maximum aantal HDD's per behuizing | 4 |
| Aantal storage drives ondersteund | 6 |
| RAID support | Y |
| Soorten RAID | 0,1,5,10 |
Interne aansluitingen
| USB 2.0 aansluitingen | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen | 2 |
| USB 3.2-connectoren (3.1 Gen 2) | 1 |
| Aantal SATA III connectors | 4 |
| Aansluiting voor audiopaneel aan voorzijde | Y |
| Voorpaneel-connector | Y |
| ATX Power connector (24-pin) | Y |
| Aansluiting voor CPU koeler | Y |
| Chassis intrusion aansluiting | Y |
| COM aansluitingen | 1 |
| TPM connector | Y |
| Parallele connector | Y |
| RGB LED-aansluitrail | Y |
Aansluitingen achterzijde
| Aantal USB 2.0-poorten | 4 |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 3 |
| Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C | 1 |
| Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| PS/2 poort(en) | 2 |
| VGA (D-Sub)poort(en) | 1 |
| Aantal HDMI-poorten | 1 |
| HDMI versie | 1.4 |
| Aantal DisplayPorts | 1 |
| DisplayPort versie | 1.4 |
| Hoofdtelefoonuitgangen | 1 |
| Lijningang | Y |
| Microfoon, line-in ingang | Y |
Netwerk
| Ethernet LAN | Y |
| Ethernet interface type | Gigabit Ethernet |
| LAN controller | Realtek RTL8111H |
| Wifi | N |
Kenmerken
| Chipset moederbord | Intel B760 |
| Audiochip | Realtek ALC897 |
| Audio-uitgangskanalen | 7.1 |
| Component voor | PC |
| Moederbord form factor | Micro ATX |
| Moederbord chipset familie | Intel |
| Type stroombron | ATX |
| Ondersteunt Windows | Windows 10 x64,Windows 11 x64 |
Uitbreidingsmodules
| Aantal M.2 (M) slots | 2 |
BIOS
| BIOS type | UEFI AMI |
| Grootte BIOS-geheugen | 256 |
| ACPI version | 6.4 |
| Clear CMOS jumper | Y |
| Systeem Management BIOS (SMBIOS) versie | 3.5 |
Gewicht en omvang
| Breedte | 243.84 |
| Diepte | 243.84 |
Inhoud van de verpakking
| Meegeleverde kabels | SATA |
