Technische specificaties
Processor
| Processorfabrikant | AMD |
| Processor socket | Socket AM5 |
| Compatibele processors | AMD Ryzen 7000 Series,AMD Ryzen 8000 Series,AMD Ryzen 9000 Series |
| Supported processor sockets | Socket AM5 |
Geheugen
| Ondersteunde geheugen types | DDR5-SDRAM |
| Aantal geheugenslots | 4 |
| Geheugen slots type | DIMM |
| Geheugen kanaal | Dual-channel |
| ECC-compatibiliteit | non-ECC |
| Supported memory clock speeds | 4800,5600 |
| Ondersteunde geheugenkloksnelheid (max) | 9000 |
| Maximum intern geheugen | 256 |
Opslag-controllers
| Ondersteunde types opslag-drives | HDD & SSD |
| Ondersteunde opslagstationinterfaces | M.2,SATA III |
| Maximum aantal HDD's per behuizing | 4 |
| Aantal storage drives ondersteund | 9 |
| RAID support | Y |
| Soorten RAID | 0,1,10 |
Grafisch
| Ingebouwde grafische adapter | N |
Interne aansluitingen
| USB 2.0 aansluitingen | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen | 4 |
| USB 3.2-connectoren (3.1 Gen 2) | 2 |
| Aantal SATA III connectors | 4 |
| Totaal aantal SATA-connectoren | 4 |
| ATX Power connector (24-pin) | Y |
| Aansluiting voor CPU koeler | Y |
| EPS power connector (8-pin) | Y |
Aansluitingen achterzijde
| Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A | 8 |
| Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C | 5 |
| Aantal USB4 Gen 2x2 poorten | 2 |
| Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| HDMI versie | 2.1 |
| Microfoon, line-in ingang | Y |
| S/PDIF-uitgang | Y |
Netwerk
| Ethernet LAN | Y |
| Ethernet interface type | 5 Gigabit Ethernet |
| Wifi | Y |
| Wifi-standaard | Wi-Fi 7 (802.11be) |
| Wi-Fi-standaarden | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax),Wi-Fi 6E (802.11ax),Wi-Fi 7 (802.11be) |
| Bluetooth | Y |
| Bluetooth-versie | 5.4 |
Kenmerken
| Chipset moederbord | AMD X870E |
| Audio-uitgangskanalen | 7.1 |
| Kleur van het product | Black |
| PC gezondheids monitor | CPU,FAN,Temperature,Voltage |
| Component voor | PC |
| Moederbord form factor | Extended ATX |
| Moederbord chipset familie | AMD |
| Ondersteunt Windows | Windows 11 x64 |
Uitbreidingsmodules
| PCI Express x16 (Gen 3.x) slots | 1 |
| PCI Express x16 (Gen 4.x) sleuven | 1 |
| PCI Express x16 (Gen 5.x) sleuven | 1 |
| Aantal M.2 (M) slots | 5 |
| 1e M.2 grootste sleutelgrootte | 2280 |
| 1e M.2 hoogste PCI Express-generatie | 5.0 |
| 2e M.2 grootste sleutelgrootte | 2280 |
| 2e M.2 hoogste PCI Express-generatie | 5.0 |
| 3e M.2 grootste sleutelgrootte | 22110 |
| 3e M.2 hoogste PCI Express-generatie | 4.0 |
| 4e M.2 grootste sleutelgrootte | 2280 |
| 4e M.2 hoogste PCI Express-generatie | 4.0 |
| 5e M.2 grootste sleutelgrootte | 2280 |
| 5e M.2 nieuwste PCI Express-generatie | 4.0 |
BIOS
| BIOS type | UEFI AMI |
| Grootte BIOS-geheugen | 256 |
| ACPI version | 6.5 |
| Systeem Management BIOS (SMBIOS) versie | 3.7 |
Gewicht en omvang
| Breedte | 304.8 |
| Diepte | 277 |
